Hi Good People,

Kindly anybody who can guide me on the right tyre sizes for my GX Cruiser HZJ105 2002 model. This machine is the best I can say. I am planning to cruise to Addis Ababa Ethiopia from Kenya and 80% of the road is rough and wild, currently I am using 265/70/16 but it looks low.

Abu


Lorin

Well-Known Member
Mar 28, 2010
1,311
322
83
Bournemouth
I believe 285/75/16 is the most common choice of size that doesn't require anything else modifying.


Paul

Well-Known Member
I am in england
Mar 1, 2010
2,465
42
48
Southampton
Garage
I put the 285's on my HZJ80 and it had a noticeable effect on hills and when loaded, not sure if yours has been tweaked or turbo'd from standard. I also found it quite difficult to find that size when I was in Sudan so might be best to use whatever the most common size in the area is and stick with standard as there are loads of 105's in that region.


Scott

Well-Known Member
Mar 17, 2010
1,033
113
63
Essex
My FZJ105 currently has 285/75/16 BFG KM2 tyres fitted, these are oversize from standard, but the engine can cope no problem. As Paul has said, this may not be the same with a HZJ.

My owners manual (pictured below) shows that my 105 was originally available with one of two tyre sizes, 275/70/16 or LT235/85/16.
I have seen 105s with different wheels which have different rim widths in some markets, the rim width has a bearing on what width of tyre can be fitted. My 105 has 8" wide rims. What width are your rims?

Don't like the adverts? Remove them by becoming a supporting member.   Click here

Scott

Well-Known Member
Mar 17, 2010
1,033
113
63
Essex
Yes. I imported an Australian at the same time, so he interprets for me. He even helped me hand wash the 105 before the Adventure Overland show!


iow_bob

Active Member
I am in north_korea
Feb 22, 2014
77
20
8
My 105 has 275/70/16 fitted as standard .
Due for new boots soon and will be going up to 285/75/16 probably hankook dyna pro mud terrains because according to reviews they are super quiet


David

Well-Known Member
Supporter
I am in great_britain
Dec 28, 2012
1,493
570
113
Leicester, United Kingdom, United Kingdom
Garage
My 105 has 275/70/16 fitted as standard .
Due for new boots soon and will be going up to 285/75/16 probably hankook dyna pro mud terrains because according to reviews they are super quiet
The 80 I had came with those tyres fitted and the 1st rock they rubbed against went though the sidewall, so I took them of and put Coopers on it


uHu

Well-Known Member
Supporter
I am in norway
Mar 7, 2010
2,089
444
83
Oslo, Norway
Yes, you should really look at what spares are available in the area. 7.5R16, or 235/85R16, could be candidates. If you actually need the higher wheels, and can live with the slightly higher CG and gearing, the 255/85R16 would be the best oversize for rough roads, or lack of such.


Grimbo

Well-Known Member
I am in great_britain
Dec 3, 2016
349
261
63
I put the 285's on my HZJ80 and it had a noticeable effect on hills and when loaded, not sure if yours has been tweaked or turbo'd from standard. I also found it quite difficult to find that size when I was in Sudan so might be best to use whatever the most common size in the area is and stick with standard as there are loads of 105's in that region.
I would second that......my 24v 1HDFT 80 series can cope with the 275/75/16 BFG AT2's and they are brilliant but.....it has affected the gearing to the degree that first can be too high with a trailer on twisty tight corners on hill's . I've fitted the CDL switch and now can use low on the tarmac without the centre diff locking so it still works for me but I reckon a fully loaded manual spec HZJ could well struggle .


clivehorridge

Well-Known Member
Guru
I am in romania
May 23, 2012
14,837
4,806
113
Comarnic, Romania
Garage
Going up in size does affect the performance of the 1HZ, well that's my experience with my 80.

It's not the end of the world, mostly a reduced top speed. So on your tour, you won't be able to cruise at 130 kph on the corregations :lol:

I'd go with what's available out there, maybe 275/70/16 but in an emergency, you'll be able to run on anything to get you home.


Robzimbo

Active Member
I am in kenya
Dec 4, 2016
51
37
18
I have Comforser MT (?!) 285/75/16 on my Standard spec 1HZ 105. Definitely less guts than is ideal, though, going slowly she will go anywhere. The tyres are half the price of BFGs, and have held up well both on and off road. I keep them at 3.2 Bar. They're a bit noisy on tar, but I can live with that.

But here's a question that I've always wanted a numerate grown-up to answer for me.

A 285/75 has a circumference of 3.14 meters (998mm diameter x Pi). A 265/65 has a circumference of 2.45 meters (778mm x Pi). The 235/85 is 818mm diameter, so a circumference of 2.7m.

That means a 285/75 rotates 320 times a kilometer, a 265/65 rotates 408 times a kilometer. The speedo is effectively set to count the number of times the wheels go round (measured from the final drive at the gearbox), and measure that against a calibrated scale of distance. So if the speedo is calibrated for 265/75 tyres, won't the speedo be reading 20- 25% below true with 285/85 boots on?

While won't make a huge difference at low speed, doesn't that mean 80kph on the clock, with the bigger tyres, is actually 105kph on the road? Which is why our trucks with big tyres don't seem to go very fast, according to the speedo, but do actually seem to more or less keep up with everything else on the road...

Maths isn't my strong point. So I may have this backward, upside down, or inside out. As I say, I'd really appreciate an answer from a numerate grown-up.

Rob


Shayne

Well-Known Member
Supporter
Guru
Feb 2, 2013
13,227
4,926
113
South Wales UK
I can't help with the math but its true the bigger the tyre the faster you go ,what makes it seem slow is your engine has to work much harder to get up to speed .

The speedo reads absolutely spot on with 285/75 cooper stt fitted to my 90 series , the mrs 90 with standard size tyres (265/70 i think) needs to do about 45 on the speedo to actually move at 30 mph .

I was looking at them Comforser tyres recently they look meaty and i was going to mention them to Clive but didn't bother because i couldn't find a worthwhile review .


Robzimbo

Active Member
I am in kenya
Dec 4, 2016
51
37
18
Hey, Shane - over the past 15 years my Cruisers have got through lots of BFGs, a couple of rotations of Bridgestone Desert Duellers, and some Pirelli Scorpions. A mix of fast tar, round town (with epic African pot-holes), and probably more than average off road ranging from desert to volcanic to black cotton soil wet and dry, and pretty much everything in between. I estimate I've driven 250,000 kms in my various LCs over that time. On average, I would say that my tyres last 50,000 Kms with the usage they get. That doesn't include the three virtually new tyres ripped to pieces on a crossing of the Marsabit shield volcano. :(

The Comforsers were fitted new by the guy I bought the 105 from as part of my negotiation with him. So I didn't pay for them, and I didn't get much choice in the matter. They worked out at approx USD200 per boot, rather than the USD400 a BFG costs in Kenya, so that's in their favor. I have the Mud Track tread, which to be honest is way chunkier than I need.

Downsides: They are really heavy tyres, with terrible 'natural balance' (the wheel guys used over a kilo of lead to get them running smoothly) - which of course reflects lower manufacturing quality, as you'd expect. They are a lot noisier than the BFG A/T on my 80 - but that's a function of the tread pattern. There's a particular, insistent noise at about 90kph, and on certain road surfaces. And I suspect they dragged the fuel consumption up, though I can't give a number on that since I've only owned the vehicle with these tyres on, and didn't drive it much before I bought it.

Upside: They're strong tyres. I've done about 10,000 kms so far, much on some rough tracks (including on volcanic rock, which is a tyre killer), and there's not a scratch on them yet. The tread is wearing reasonably well. I run them at 3.2 Bar (46PSI), and they grip well in the wet.

Conclusion; If I had another thousand dollars spare to spend next time I change tyres, I might go back to BFGs. But so far, the Comforser M/T are wearing well, dealing with the terrain, and rolling smoothly on wet roads and dry. I don't know what the price differential is in the UK, but for half the price of the best, I reckon they are better than half as good.

Let me know if you want any other detail.

Best regards,

Rob

  • Like
Reactions: Shayne

GeekOKent

Well-Known Member
Supporter
I am in uk
Jul 1, 2013
2,244
669
113
Cambridge
i am running 235/85r16's on the 105 - based on the fact that the 1HZ can do with the lesser rolling friction, and also the very wide spread availability of this tyre size around the place ( not that I've replaced one yet... but when looking, i did find it was easy to find all over the place ). I guess someone / something more popular than a LandCruiser also uses the same tyre size.

running on bfg ko2's at the moment.

the truck came with general ameritrack AT - very very hard compound, it was very unsettling driving on those. to a point where i thought it was the suspension that was shot.


GeekOKent

Well-Known Member
Supporter
I am in uk
Jul 1, 2013
2,244
669
113
Cambridge
I've also found that running between 42 and 44 psi, both front and rear, is the best overall drive. I guess the handbook numbers ( 38 / 54 ) are based on stock truck, running the full stock load.
